9. ON THE SITE
PREPARATION OF WELDED STYLE SECTIONS FOR USE
Welded style sections are permanent tubes. Sketches are shown below. No assembly of this
section style is needed, providing the cable assemblies are properly attached.
Occasionally, Welded style regular sections that have been stacked for storage or transport can
get stuck together. To get them apart, lie the bundle on its side and have two people “row” the
chute sections apart.
If this technique does not work, use a winch to pull the sections apart.
If all of the sections you will be using are of the Welded style, then please proceed to page
29.
Push with feet
Pull with hands
Top Hopper Section
Regular Section
Door Section
