5.0 DIAGNOSTICS, VERIFICATION, AND TROUBLESHOOTING
5.1 Performing a Diagnostics Test
The Diagnostics test mode displays the output voltage at the X leads (V
x
), the voltage sensed by
the H leads (V
h
), and the X voltage excitation current (I
x
). These values can then be verified
using an external volt meter and ampere meter. The Diagnostic Test mode uses the X1-X2 taps.
To perform a diagnostic test:
a. Start from the “START-UP” menu:
Press the [4] key (DIAGNOSTIC).
b. The following screen will be displayed:
Select the maximum output voltage on the X terminals by pressing the corresponding
key (
[1] – [4] ).
c. The following screen will be displayed:
Press the [ENTER] key to continue.
d. The following screen will be displayed and the V
x
, V
h
, and I
x
values will be continuously
updated for 15 seconds:
You can press the [PAPER ∧ Contrast] or [PAPER ∨ Contrast] key to increase or
decrease the V
x
voltage, respectively. You can press the [STOP] key to end the test
immediately and return to the “START-UP” menu.
The test will automatically end after 15 seconds, and you will be returned to the
“START-UP” menu.
DIAGNOSTIC
Vx = 3.3 Ix = 0.0227
Vh = 0.03
↑/↓ - “STOP” TO EXIT
CAUTION! CABLES WILL
BE ENERGIZED!
“ENTER” TO CONTINUE
SELECT VOLTAGE RANGE
1. 50V 2. 250V
3. 500V 4. 1500V
1. RUN TEST 09/24/09
2. SETUP 08:20:19
3. TEST PLANS
4. DIAGNOSTIC
