REV 3 EZCT S2 USER’S MANUAL

Press the

[START]

key to begin the test.

f. The EZCT S2 will start performing the test per the test plan parameters. When the test

has finished, the following screen will be displayed:

Press any key to continue.

g. The following screen will be displayed:

Press the

[1]

key (YES) if you would like to print the test results.

Press the

[2]

key (NO) if you do not want to print the test results.

h. The following screen will be displayed:

Press the

[1]

key (YES) to keep the test results.

i. The following screen will be displayed:

Press any key to continue.

j. The following screen will be displayed:

SAVE THIS RECORD?
1.YES
2.NO

TEST 2 SAVED

KEEP THIS TEST?
1.YES
2.NO

PRINT TEST RESULTS?

1.YES
2.NO

ANY KEY TO CONTINUE

Vx=77.6 Vh=0.3876
I=0.0522 RAT=+200.08

TEST 1 PARAMETERS:
1500V 1.0A X1-X2
“START” TO BEGIN
