EZCT S2 USER’S MANUAL
REV 3
26
3.3.3. Printing a Directory of Test Records Stored in the EZCT S2’s Memory
You can print a directory of all the test records stored in the EZCT S2’s Flash EEPROM using the
steps below:
a. Start from the “START-UP” menu:
Press the
[2]
key (SETUP).
b. The following screen will be displayed:
Press the
[4]
key (NEXT PAGE).
c. The following screen will be displayed:
Press the
[1]
key (RECORD DIRECTORY).
d. The following screen will be displayed:
Press the
[1]
key to print a full directory listing of all the test records stored in the EZCT
S2’s Flash EEPROM. The directory listing will be printed on the thermal printer and you
will be returned to the “START-UP” menu. A sample directory listing printout is shown in
Figure 7.
Press the
[2]
key to print a short directory listing of the stored test records. The short
directory option prints the last 10 records stored in the EZCT S2’s Flash EEPROM. The
short directory listing will be printed on the thermal printer and you will be returned to
the “START-UP” menu.
PRINT DIRECTORY
1.
FULL DIRECTORY
2.
SHORT DIRECTORY
1.
RECORD DIRECTORY
2.
ERASE RECORD
3.
KNEE POINT MARKER
4.
NEXT PAGE
1.
RECORD ID
2.
PRINT RECORD
3.
RESTORE RECORD
4.
NEXT PAGE
1.
RUN TEST 09/24/09
2.
SETUP 08:20:19
3.
TEST PLANS
4.
DIAGNOSTIC
