EZCT S2 USER’S MANUAL REV 3
44
4.0 CHANGING SETUP PARAMETERS
4.1 Setting the Knee Point Marker
Use the steps below to change the knee point marker for the excitation graph:
a. Start from the “START-UP” menu:
Press the [2] key (SETUP).
b. The following screen will be displayed:
Press the
[4]
key (NEXT PAGE).
c. The following screen will be displayed:
Press the [3] key (KNEE POINT MARKER)
d. The following screen will be displayed:
Press either the [1] key (IEEE 30 DEGREE), the [2] key (IEEE 45 DEGREE), or the [3] key
(ASA 10%V-->50%I) to select the desired knee point marker. The knee point marker will
be set and you will be returned to the “START-UP” menu. A graphic report showing the
knee point marker is shown in Figure 10.
1. IEEE 30 DEGREE
2. IEEE 45 DEGREE
3. ASA 10%V --> 50%I
1. RECORD DIRECTORY
2. ERASE RECORD
3. KNEE POINT MARKER
4. NEXT PAGE
1. RECORD ID
2. PRINT RECORD
3. RESTORE RECORD
4. NEXT PAGE
1. RUN TEST 12/04/09
2. SETUP 10:47:17
3. TEST PLANS
4. DIAGNOSTIC
