REV 3 EZCT S2 USER’S MANUAL

NOTE

The “HIGH VOLTAGE PRESENT” light will be illuminated to indicate that high
voltage is present.

k. If the selected test included a ratio test, the following screen will be displayed:

When the ratio test is complete, the final results will be displayed:

Press any key on the keypad to continue.

l. The following screen will be displayed:

Press the

[1]

key (YES) if you would like to print the test results. The test results will be

printed on the thermal printer. A typical EZCT S2 tabulated test report printout is shown
in Figure 5. A typical graphic report is shown in Figure 6.

Press the

[2]

key (NO) if you do not want to print the test results.

m. The following screen will be displayed:

Press the

[1]

key (YES) to keep the test results.

KEEP THIS TEST?
1. YES
2. NO

PRINT TEST RESULTS?

1. YES
2. NO

ANY KEY TO CONTINUE

Vx= 39.9 Vh= 0.4984
I=0.1324 RAT=+80.058

RATIO TEST

Vx= 39.9 Vh= 0.4984
I=0.1324 RAT=+80.058
