EZCT S2 USER’S MANUAL REV 3
16
Press the
[ENTER]
key. Continue to step h.
2. NO
Press the [2] key if you do not want to enter the CT nameplate values. Continue
to step h.
h. The following screen will be displayed:
Use the alpha-numeric keys on the keypad to enter a test note. The test note field is 20
characters long. One test note can be saved for each test.
When pressing a key, the corresponding number on the key will be displayed first.
Pressing the key again will display the first letter on the key. Pressing the key again will
display the second letter on the key. For example, to type the letter “A”, you must press
the
[2] key twice. To erase the character at the cursor position, press the [CLEAR] key.
Press the [PAPER ∧ Contrast] button to move to the next character. Press the
[PAPER ∨ Contrast] key to move to the previous character. Press the [ENTER] key
when you are done typing the note.
i. The following screen will be displayed:
Press the
[START]
key to begin running the test.
j. If the selected test included an excitation test, the following screen will be displayed:
CABLES ENTERGIZED!
1500V 1.0A X1-X2
I = 0.6810 AMPS
V = 61.0 VAC
TEST 1 PARAMETERS:
1500V 1.0A X1-X2
“START” TO BEGIN
ENTER TEST 1 NOTE:
↑/↓ TO POSITION
“ENTER” TO ACCEPT
ENTER PLATE RATIO:
80 : 1.0
