EZCT S2 USER’S MANUAL REV 3
28
3.3.4. Erasing Test Records From the Flash EEPROM
You can erase individual or all test records stored in the EZCT S2’s Flash EEPROM. To erase a
test record:
a. Start from the “START-UP” menu:
Press the
[2]
key (SETUP).
b. The following screen will be displayed:
Press the [4] key (NEXT PAGE).
c. The following screen will be displayed:
Press the
[2]
key (ERASE RECORD).
d. The following screen will be displayed:
1. ERASE SINGLE REC.
Press the
[1]
key (ERASE SINGLE REC.) if you would like to erase a single record.
The following screen will be displayed:
Type the record number to be erased and press the
[ENTER]
key.
ERASE RECORD
NUMBER:
ERASE RECORD
1. ERASE SINGLE REC.
2. ERASE ALL RECORDS
1. RECORD DIRECTORY
2. ERASE RECORD
3. KNEE POINT MARKER
4. NEXT PAGE
1. RECORD ID
2. PRINT RECORD
3. RESTORE RECORD
4. NEXT PAGE
1. RUN TEST 09/24/09
2. SETUP 08:20:19
3. TEST PLANS
4. DIAGNOSTIC
