EZCT-2000A USER’S MANUAL REV 1
82
4.4 Printing Raw Memory Buffer Data
You can print the raw data from the EZCT-2000A’s memory buffer for diagnostic purposes. This
will print a table of current and voltage values stored in the unit’s working memory. To print the
raw buffer data:
a. Start from the “START-UP” menu:
Press the [2] key (SETUP).
b. The following screen will be displayed:
Press the [6] key (NEXT PAGE).
c. The following screen will be displayed:
Press the [4] key (PRINT RAW DATA). The raw buffer data will be printed and you will be
returned to the “START-UP” menu.
1. SET TIME
2. buried ct in delta
3. knee point marker
4. print raw data
1. RECORD ID
2. PRINT RECORD
3. RECORD DIRECTORY
4. SAVE/RES RECORD
5. ERASE RECORD
6. NEXT PAGE
1. RUN TEST 02/16/10
2. SETUP 10:24:25
3. TEST PLANS
4. DIAGNOSTIC
