EZCT-2000A USER’S MANUAL REV 1
70
c. The following screen will be displayed:
Use the alpha-numeric keys on the keypad to enter a test note and press the [ENTER]
key.
d. The following confirmation screen will be displayed showing the test parameters:
Press the [START] key to begin the test.
e. The EZCT-2000A will start performing the test per the test plan parameters. When the
test has finished, the following screen will be displayed:
Press any key to continue.
f. The following screen will be displayed:
Press the [1] key (YES) if you would like to print the test results.
Press the
[2]
key (NO) if you do not want to print the test results.
print test results?
1. YES
2. NO
ANY KEY TO CONTINUE
V
x
=77.6 V
H
=0.3876
I=0.0522 RAT=+200.08
TEST 1 parameters:
300V
2.0A x1-x2
"START" to begin
ENTER TEST 1 NOTE:
_
↑↓
to position
"ENTER" TO ACCEPT
