REV 1 EZCT-2000A USER’S MANUAL
19
NOTE
If you had selected a test current greater than 1 Amp in step e, the following
screen will be displayed:
Press any key to continue.
Type the burden value using the keypad and then press the [ENTER] key.
j. The following screen will be displayed:
Type the Cos
ϕ value using the keypad and then press the [ENTER] key.
k. The following screen will be displayed:
Select the rated secondary current by pressing the [1] key (5A) or [2] key (1A).
rated secondary cur:
1. 5A
2)1A
ENTER cos
ϕ
:
(0.00 - 1.00)
0.0
ENTER BURDEN VA:
(500.0 max)
0.0
SATURATION CUR WILL
BE REDUCED TO 1 AMP.
(PRESS ANY KEY...)
