EZCT-2000A USER’S MANUAL
REV 1
20
l. The following screen will be displayed showing a summary of the test parameters:
Press the
[START]
key to start the test.
m. If the selected test included a resistance test, the following screen will be displayed
momentarily:
The following screen will then be displayed:
NOTE
The “HIGH VOLTAGE PRESENT” light will be illuminated to indicate that high
voltage is present.
n. If the selected test included a ratio test, the following screen will be displayed
momentarily:
The following screen will then be displayed:
CABLES ENERGIZED!
1200V
1.0A
x1-x2
I= 0.0004 AMPS
V= 34.2 VAC
CABLES ENERGIZED!
1200V
1.0A
x1-x2
RESISTANCE = 215.1
Ω
CABLES ENERGIZED!
1200V
1.0A
x1-x2
DC RESISTANCE TEST
TEST 1 parameters:
1200V
1.0A
x1-x2
"START" to begin
