CT-7000 Operating Instructions
56
9.16 English/Metric or Rotary Transducer Selection
The CT-7000 supports and displays both English and Metric calculations from the breaker's
travel parameters such as the stroke, velocity and other parameters. The user can switch from
one system to the other by following the steps in Table 20.0. Rotary transducer requires the user to
enter the defined linear distance in millimeters or inches, per one degree of rotary motion as seen
in Table 21.
Table 20.0 Select Metric Units of Measure
STEP OPERATION ACTION DISPLAY
1 SELECT SET UP MENU. PRESS # 3 KEY. 1. ANALYSIS POINT
2. MEASUREMENT UNITS
3. SAVE / RESTORE
4. NEXT PAGE
2 SELECT MEASUREMENT UNITS. PRESS # 2 KEY. SELECT UNITS
1. ENGLISH
2. METRIC
3. ROTARY TRANSDUCER
3 SELECT METRIC. PRESS # 2 KEY. 1. TIME BRKR
2. GET RSLT
3. SET UP
4. DIAGNOSTIC
Table 21.0 Select Rotary Transducer
STEP OPERATION ACTION DISPLAY
1 SELECT SET UP MENU. PRESS # 3 KEY. 1. ANALYSIS POINT
2. MEASUREMENT UNITS
3. SAVE / RESTORE
4. NEXT PAGE
2 SELECT MEASUREMENT UNITS. PRESS # 2 KEY. SELECT UNITS
1. ENGLISH
2. METRIC
3. ROTARY TRANSDUCER
3 SELECT ROTARY TRANSDUCER. PRESS # 3 KEY. ROTARY ENCODER:
1. ENGLISH (In./deg)
2. METRIC (MM/deg)
4 SELECT INCH PER DEGREE. PRESS #1 KEY. INCHES/DEGREE
0.014 in/deg
5 ENTER 0.50 INCH PER DEGREE. ENTER 0.50 USING 0-
9 KEYS.
INCHES/DEGREE
0.500 in/deg
6 RETURN TO MAIN MENU. PRESS THE “ENTER”
KEY.
1. TIME BRKR
2. GET RSLT
3. SET UP
4. DIAGNOSTIC
