WaveStation SCPI
Parameters Value Description
START Where may be the same as the basic wave frequency.
TRSR {EXT, INT, MAN} Sets trigger source to EXTernal, INTernal, or MANual.
TRMD {ON|OFF} Turns on/off trigger output. Parameter is invalid if TRSR is EXT.
SWMD {LINE|LOG} Sets sweep mode to LINEear or LOGarithmic
DIR {UP|DOWN} Sweep direction.
EDGE {RISE|FALL} Use rising or falling edge. Parameter is valid only when TRSR is EXT.
MTRIG Triggers the device once. Parameter is valid only when TRSR is MAN.
CARR,WVTP Where carrier := {SINE, SQUARE, RAMP, ARB}.
(CARR,)FRQ
Where carrier wave := {default unit is Hz; minimum 1xe-6 Hz,
maximum depends on the WaveStation model}.
(CARR,)AMP
Where carrier wave := {default unit is V;
WS2000 Channel 1 min. 0.004V, max. 6V; Channel 2 min. 0.004V, max. 20V
WS3000 Channel 1 and 2 min. 2mVpp, max. 20Vpp}.
(CARR,)OFST
Where carrier wave := {default unit is V; maximum depends on the
WaveStation model}.
(CARR,)SYM Where carrier wave := {0% to 100%}.
(CARR,)DUTY
Where carrier wave := {20 to 80}. Parameter is valid only when
CARR,WVTP is SQUARE.
(CARR,)PHSE Where carrier wave := {0 to 360}.
QUERY SYNTAX
:SWeepWaVe?
:= {C1|C2}
RESPONSE := {all current Sweep Wave parameters}
EXAMPLE 1 Set Channel 1 sweep time to one second.
C1:SWWV STATE,ON,TIME,1S
EXAMPLE 2 Read Channel 2 Sweep Wave parameters (when STATE is ON).
C2:SWWV?
Return:
C2:SWWV STATE,ON,TIME,1S,STOP,100HZ,START,100HZ,
TRSR,MAN,TRMD,OFF,SWMD,LINE,DIR,UP,CARR,WVTP,SQUARE,
FRQ,1000HZ,AMP,4V,OFST,0V,DUTY,50
EXAMPLE 3 Read Channel 2 Sweep Wave parameters (when STATE is OFF).
C2:SWWV?
Return:
C2:SWWV STATE,OFF
