Command Reference
WaveStation 3000 Arbitrary Waveform Values
Index Name Index Name Index Name Index Name Index Name
0 StairUp 8 Sqrt 16 Gmonopuls 24 Blackman 32 Asin
1 StairDn 9 X^2 17 Cardiac 25 GaussiWin 33 Acos
2 StairUD 10 Sinc 18 Quake 26 Harris 34 Atan
3 Trapezia 11 Gaussian 19 TwoTone 27 Bartlett 35 ACot
4 ExpFall 12 Dlorentz 20 SNR 28 Tan
5 ExpRise 13 Haversine 21 Hamming 29 Cot
6 LogFall 14 Lorentz 22 Hanning 30 Sec
7 LogRise 15 Gauspuls 23 Kaiser 31 Csc
Indices 36-59 are reserved for user-defined waveforms up to 16K; indices 60-67 are for user-defined
waveforms up to 512K.
BSWV - Basic Wave Command
DESCRIPTION Sets or retrieves basic waveform parameters.
SYNTAX
:BaSicWaVe
:= {C1|C2}
:= {a parameter from the table below}
IMPORTANT: If the command doesn’t specify wave type (WVTP), the remaining parameters are
applied to the waveform type already selected on your WaveStation.
Parameters Value Description
WVTP Where := {SINE, SQUARE, RAMP, PULSE, NOISE, ARB ,DC}
FRQ
Where := {default unit is Hz; minimum value 1xe-6 Hz, maximum
value depends on the model}. If WVTP is NOISE, parameter is invalid.
AMP
Where := {default unit is V;
WS2000 Channel 1 min. 0.004V, max. 6V; Channel 2 min. 0.004V, max. 20V
WS3000 Channel 1 and 2 min. 2mVpp, max. 20Vpp}.
If WVTP is NOISE, parameter is invalid.
OFST
Where := {default unit is V; maximum value depends on the
WaveStation model}. If WVTP is NOISE, parameter is invalid.
SYM Where :={0 to 100}. Parameter valid only when WVTP is RAMP.
DUTY
Where := {if WVTP is SQUARE, 20% to 80%; if WVTP is PULSE,
0.1% to 99.9%}.
PHSE Where := {0 to 360}. If WVTP is NOISE, parameter is invalid.
STDEV
deviation>
Where := {default unit is V; min. 0.5mV; WS2000 max.
1.625V, WS3000 max. 1.599V}. Parameter is valid only when WVTP is NOISE.
922829 Rev C 15
