Command Reference
Parameters Value Description
(PM,)MDSP
Where PM := {SINE, SQUARE, TRIANGLE, UPRAMP,
DNRAMP, NOISE, ARB}. Parameter is valid only when PM,SRC is INT.
(PM,)FRQ
Where PM := {WS2000 0.002Hz to 20000Hz; WS3000
0.001Hz to 50000Hz}. Parameter is valid only when PM,SRC is INT.
(PM,)DEVI
Where PM := {0 to 360}. Parameter is valid only when
PM,SRC is INT.
(PWM,)FRQ
Where pulse wave < frequency>:= {0Hz to 4kHz}. Parameter is valid only
when CARR,WVTP is PULSE.
(PWM,)DEVI
deviation>
Where pulse wave := {depends on carrier waveform
duty cycle}. Parameter is valid only when CARR,WVTP is PULSE.
(PWM,)MDSP
Where pulse := {SINE, SQUARE, TRIANGLE, UPRAMP,
DNRAMP, NOISE, ARB}. Parameter is valid only when CARR,WVTP is
PULSE.
(PWM,)SRC {INT|EXT} Sets pulse wave signal source to INTernal or EXTernal.
(ASK,)SRC {INT|EXT} Sets ASK signal source to INTernal or EXTernal.
(ASK,)KFRQ
frequency>
Where := {WS2000 0.002Hz to 20000Hz; WS3000
0.001Hz to 1MHz}. Parameter is valid only when ASK,SRC is INT.
(FSK,)KFRQ
Where FSK := {WS2000 0.002Hz to 50000Hz; WS3000
0.001Hz to 1MHz}. Parameter is valid only when FSK,SRC is INT.
(FSK,)HFRQ Where FSK := {same as basic waveform frequency}.
(FSK,)SRC {INT|EXT} Sets FSK signal source to INTernal or EXTernal.
(CARR,)WVTP Where carrier := {SINE, SQUARE, RAMP, ARB, PULSE}.
(CARR,)FRQ
Where carrier wave := {default unit is Hz; minimum value is
1xe-6 Hz, maximum value depends on the WaveStation model}.
(CARR,)AMP
Where carrier wave := {default unit is V; Channel 1 minimum
0.004V, maximum 6V; Channel 2 minimum 0.004V, maximum is 20V).
(CARR,)OFST Where carrier wave := {default unit is V}.
(CARR,)SYM Where carrier wave := {0% to 100%}.
(CARR,)DUTY
Where carrier wave := {if CARR,WVTP is SQUARE, 20% to
80%; if CARR,WVTP is PULSE, 0.1% to 99.9%}.
(CARR,)PHSE Where carrier wave := {0 to 360}.
(CARR,)RISE Value of rise.
(CARR,)FALL Value of fall.
(CARR,)DLY Value of delay.
922829 Rev C 21
