Command Reference
STL? - Store List Query
DESCRIPTION Retrieves the names of waveforms saved to WaveStation memory units. If a
user-defined memory unit (M50-M59 on WaveStation 2000 models and M36-M67
on WaveStation 3000 models) does not have a saved waveform, the query returns
the string “EMPTY”.
SYNTAX
SToreList?
RESPONSE (example from WaveStation 2000)
STL M0,SINE,M1,NOISE,M2,STAIRUP,M3,STAIRDN,M4,STAIRUD,
M5,PPULSE,M6,NPULSE,M7,TRAPEZIA,M8,UPRAMP,M9,DNRAMP,
M10,EXP_FALL,M11,EXP_RISE,M12,LOGFALL,M13,LOGRISE,M14,SQRT,
M15,ROOT3,M16,x^2,M17,x^3,M18,SINC,M19,GUSSIAN,M20,DLORENTZ,
M21,HAVERSINE,M22,LORENTZ,M23,GAUSPULS,M24,GMONOPULS,
M25,TRIPULS,M26,CARDIAC,M27,QUAKE,M28,CHIRP,M29,TWOTONE,
M30,SNR,M31,EMPTY,M32,EMPTY,M33,EMPTY,M34,HAMMING,
M35,HANNING,M36,KAISER,M37,BLACKMAN,M38,GAUSSWIN,M39,TRIANG,
M40,BLACKMANHARRIS,M41,BARTLETT,M42,TAN,M43,COT,M44,SEC,
M45,CSC,M46,ASIN,M47,ACOS,M48,ATAN,M49,ACOT,M50,EMPTY,
M51,EMPTY,M52,EMPTY,M53,EMPTY,M54,EMPTY,M55,EMPTY,M56,EMPTY,
M57,EMPTY,M58,EMPTY,M59,EMPTY
SWWV - Sweep Wave Command
DESCRIPTION Sets sweep parameters or retrieves current Sweep Wave settings.
SYNTAX
:SWeepWaVe ,…
:= {C1|C2}
:= {a parameter from the table below}
:= {a value from the table below}
IMPORTANT: Carrier wave type cannot be PULSE or NOISE. Set STATE ON and specify carrier wave type
before other CARR parameters (e.g., C1:SWWV STATE,ON,CARR,WVTP,SINE,…). Once set, you do not
need to repeat CARR before other parameters; it is shown here to indicate which parameters can
follow it.
Parameters Value Description
STATE {ON|OFF} Turns on/off sweep. To set other Sweep Wave parameters, first set
STATE ON.
TIME Sweep time where := {0.001S to 500S}.
STOP Where may be the same as the basic wave frequency.
922829 Rev C 25
