WaveStation SCPI
ARWV - Arbitrary Wave Command
DESCRIPTION Changes the arbitrary waveform type.
SYNTAX
:ARbWaVe {INDEX|NAME},
:= {C1|C2}
:= {number from tables below}
:= {name from the tables below}
IMPORTANT: Use only one parameter, either INDEX or NAME, in a single Arbitrary Wave command.
QUERY SYNTAX
:ARbWaVe?
:= {C1|C2}
RESPONSE
:ARbWaVe INDEX,,NAME,
EXAMPLE 1 Set StairUp arbitrary waveform output by index.
C1:ARWV INDEX,2
EXAMPLE 2 Set Atan arbitrary wave output by name.
C2:ARWV NAME,ATAN
EXAMPLE 3 Read current arbitrary waveform type.
C1:ARWV?
Return:
C1:ARBWAVE INDEX,2,NAME,StairUp
RELATED BSWV
WaveStation 2000 Arbitrary Waveform Values
Index Name Index Name Index Name Index Name Index Name
2 StairUp 11 Exp_Rise 20 Dlorentz 29 Twotone 41 Bartlett
3 StairDn 12 LogFall 21 Haversine 30 Snr 42 Tan
4 StairUD 13 LogRise 22 Lorentz 34 Hamming 43 Cot
5 PPulse 14 Sqrt 23 Gauspuls 35 Hanning 44 Sec
6 NPulse 15 Root3 24 Gmonopuls 36 Kaiser 45 Csc
7 Trapezia 16 X^2 25 Tripuls 37 Blackman 46 Asin
8 UpRamp 17 X^3 26 Cardiac 38 Gausswin 47 Acos
9 DnRamp 18 Sinc 27 Quake 39 Triang 48 Atan
10 Exp_Fall 19 Gussian 28 Chirp 40 BlackmanHarris 49 Acot
Indices 50-60 are reserved for user-defined waveforms.
14 922829 Rev C
