Teledyne LeCroy Corporation Sierra M6-4 and Sierra M6-2 Port Configurations Reference Manual
69 69
3.1.3.15 Single Port Analyzer + Device Emulator (Port 1) (API Index_ADE _ 0 =
92)
Ports configuration:
Port 1 Port 2
-
Internal Connection:
Figure 3-16 Single port Analyzer + Device Emulator (Port 1)
T e l e d y n e L e C r o y S i e r r a M 6 - 2 S y s t e m
Device Emulator
DE on Port 1
Analyzer
Analysis on Port 1
Port 1 Port 2
T1 I1 T2 I2
