Teledyne LeCroy Corporation Sierra M6-4 and Sierra M6-2 Port Configurations Reference Manual
15 15
2.2.1.9 Two Ports Device Emulator (Ports 1, 2) (API Index _DE_DE_0_0 = 24)
Ports configuration:
Port 1 Port 2 Port 3 Port 4
- -
Internal Connection:
Figure 2-9 Two ports Device Emulator (Ports 1, 2)
2.2.1.10 Two Ports Device Emulator (Ports 3, 4) (API Index_0_0_DE_DE = 23)
Ports configuration:
Port 1 Port 2 Port 3 Port 4
- -
Internal Connection:
Figure 2-10 Two ports Device Emulator (Ports 3, 4)
T e l e d y n e L e C r o y S i e r r a M 6 - 4 S y s t e m
Pass through
not used
Pass through
not used
Device Emulator
Dev Emul on Port 1
Device Emulator
Dev Emul on Port 2
Port 1 Port 3 Port 4
T1 I1 T2 I2 T3 I3 T4 I4
Port 2
T e l e d y n e L e C r o y S i e r r a M 6 - 4 S y s t e m
Device Emulator
Dev Emul on Port 3
Device Emulator
Dev Emul on Port 4
Pass through
not used
Pass through
not used
Port 3 Port 4
T1 I1 T2 I2 T3 I3 T4 I4
Port 1 Port 2
