Teledyne LeCroy Corporation Sierra M6-4 and Sierra M6-2 Port Configurations Reference Manual
63 63
3.1.3.3 Single Port Host Emulator (Port 1)
Ports configuration:
Port 1 Port 2
-
Internal Connection:
Figure 3-4 Single port Host Emulator (Port 1)
3.1.3.4 Single Port Host Emulator – Port 2
Ports configuration:
Port 1 Port 2
-
Internal Connection:
Figure 3-5 Single Port Host Emulator (Port 2)
T e l e d y n e L e C r o y S i e r r a M 6 - 2 S y s t e m
Host Emulator
HE on Port 1
Pass through
Port 1 Port 2
T1 T2 I2
T e l e d y n e L e C r o y S i e r r a M 6 - 2 S y s t e m
Pass through
not used
Host Emulator
Port 2 Port 1
T1 I1 T2
