Teledyne LeCroy Corporation Sierra M6-4 and Sierra M6-2 Port Configurations Reference Manual
32 32
2.2.3.7 Single Port Jammer + Analyzer on post (Port 3) (API Index _
0_0_JA_0 = 27)
Ports configuration:
Port 1 Port 2 Port 3 Port 4
- - -
Internal Connection:
Figure 2-42 Single port Jammer + Analyzer on post (Port 3)
2.2.3.8 Single Port Jammer + Analyzer on post (Port 4) (API Index _
0_0_0_JA = 28)
Ports configuration:
Port 1 Port 2 Port 3 Port 4
- - -
Internal Connection:
Figure 2-43 Single port Jammer + Analyzer on post (Port 4)
T e l e d y n e L e C r o y S i e r r a M 6 - 4 S y s t e m
Pass through
not used
Jammer
Jammer on Port 4
Analyzer
Analysis after JAM
Pass through
not used
Port 2 Port 3 Port 4 Port 1
T1 I1 T2 I2 T3 I3 T4 I4
T e l e d y n e L e C r o y S i e r r a M 6 - 4 S y s t e m
Jammer
Jammer on Port 3
Pass through
not used
Analyzer
Analysis after JAM
Pass through
not used
Port 2 Port 4 Port 3 Port 1
T1 I1 T2 I2 T3 I3 T4 I4
