Teledyne LeCroy Corporation Sierra M6-4 and Sierra M6-2 Port Configurations Reference Manual
9
9
2.1.4
Jammer and Emulator Configurations
Configuration
Port 1
Port 2
Port 3
Port 4
Section
1
Single Port Jammer (Port 1)+ Two Ports Initiator Emulator
J
P
HE
HE
2
Single Port Jammer (Port 2)+ Two Ports Initiator Emulator
P
J
HE
HE
3
Single Port Jammer (Port 3)+ Two Ports Initiator Emulator
HE
HE
J
P
4
Single Port Jammer (Port 4)+ Two Ports Initiator Emulator
HE
HE
P
J
5
Single Port Jammer (Port 3)+ Single Port Initiator Emulator
HE
P
J
P
6
Single Port Jammer (Port 1) + Single Port Analyzer/Initiator
Emulator
J
P
A/HE
P
7
Single Port Jammer (Port 3) + Single Port Analyzer/Initiator
Emulator
A/HE
P
J
P
8
Single Port Jammer (Port 1)+ Two Ports Target Emulator
J
P
DE
DE
9
Single Port Jammer (Port 2)+ Two Ports Target Emulator
P
J
DE
DE
10
Single Port Jammer (Port 3)+ Two Ports Target Emulator
DE
DE
J
P
11
Single Port Jammer (Port 4)+ Two Ports Target Emulator
DE
DE
P
J
12
Single Port Jammer (Port 3)+ Single Port Target Emulator
DE
P
J
P
13
Single Port Jammer (Port 1) + Single Port Analyzer/Target
Emulator
J
P
A/DE
P
14
Single Port Jammer (Port 3) + Single Port Analyzer/Target
Emulator
A/DE
P
J
P
2.1.5
Two Ports Jammer Configurations
Configuration
Port 1
Port 2
Port 3
Port 4
Section
1
Two Ports Jammer + Two Ports Analyzer
J
J
A
A
2
Two Ports Analyzer + Two Ports Jammer
A
A
J
J
3
Two Ports Jammer/Analyzer (Port 1 And Port 2)
J/A
J/A
P
P
4
Two Ports Jammer/Analyzer (Port 3 And Port 4)
P
P
J/A
J/A
5
Two Ports Jammer + Two Ports Host Emulator
J
J
HE
HE
6
Two Ports Host Emulator + Two Ports Jammer
HE
HE
J
J
7
Two Ports Jammer + Two Ports Device Emulator
J
J
DE
DE
8
Two Ports Device Emulator + Two Ports Jammer
DE
DE
J
J
9
Analyzer/Host Emulator + Two Ports Jammer
A/HE
P
J
J
10
Two Ports Jammer + Analyzer/Host Emulator
J
J
A/HE
P
11
Analyzer/Device Emulator + Two Ports Jammer
A/DE
P
J
J
12
Two Ports Jammer + Analyzer/Device Emulator
J
J
A/DE
P
