Acer 230 User Manual
Page 80
72
TravelMate 230/ 280
7.
Remove the inverter cable from the main board with a plastic flat screwdriver.
8.
Remove the LCD module from the main unit carefully.
9.
Disconnect the launch board cable from the main board and remove it.
NOTE: Please arrange the inverter cable and the coaxial cable well in the way as shown after you connect
them to the main board.
