Acer 230 User Manual
Page 135
Chapter 6
127
Case/Cover/Bracket Assembly
5
BATTERY COVER
COVER BATTERY PELICAN
NS
HDD BRACKET
ASSEMBLY HDD BRACKET PELICAN
13
CHARGER PLATE
ASSEMBLY CHARGER PLATE
PELICAN
14
HEATSINK PLATE
ASSEMBLY HEAT PLATE PELICAN
6
HDD COVER
COVER HDD PELICAN
12
MODEM COVER W/SCREW
ASSEMBLY MODEM COVER
PELICAN
NS
CD-ROM BRACKET
BRACKET CD ROM PELICAN
No.
Partname
Description
