Acer 230 User Manual
Page 139
Chapter 6
131
NS
ADAPTER 70W 3PIN DELTA ADP-
65DBBE
ADT 70W ADP-65DBBE 3P
Keyboard
NS
KEYBOARD NSK-84X21 US
KB US NSK-84X21
Speaker
NS
SPEAKER PACK LEFT/RIGHT
SPEAKER PELICAN
Heatsink
3
CPU HEATSINK
SINK HEAT CPU PELICAN
Fan
17
CPU FAN SINK W/ FAN
ASSEMBLY FAN PELICAN
FDD/Floppy Disk Drive
15
FDD MODULE 1.44M MITSUMI
ASSY UNIT FDD MITSUMI PELICAN
Combo Drive
No.
Partname
Description
