Acer 230 User Manual
Page 126
118
TravelMate 230/280
Case/Cover/Bracket Assembly
5
BATTERY COVER
COVER BATTERY PELICAN
NS
LCD SUPPORT BRACKET LEFT
14"
BRACKET SUPPORT L 141 LCD S50
NS
LCD SUPPORT BRACKET RIGHT
14"
BRACKET SUPPORT R 141 LCD S50
NS
HDD BRACKET
ASSEMBLY HDD BRACKET PELICAN
13
CHARGER PLATE
ASSEMBLY CHARGER PLATE
PELICAN
14
HEATSINK PLATE
ASSEMBLY HEAT PLATE PELICAN
6
HDD COVER
COVER HDD PELICAN
No.
Partname
Description
This manual is related to the following products:
