Acer 230 User Manual
Page 140
132
TravelMate 230/280
NS
COMBO DRIVE 8/24/10/24X KME
UJA74OAC6 F4
COMBO 8,24/10/24 UJA74OAC6 F4
Main board
9
MAINBOARD PELICAN W/ COIN
BATTERY, I/O BRACKET,
MODEM CABLE, PCMCIA PLATE
& PCMCIA SLOT
PELICAN MB (DIP) W/O CPU VER-SB
Miscellaneous
NS
TOUCHPAD BUTTON SCROLL
BUTTON TOUCHPAD SCROLL
NS
TOUCHPAD BUTTON PAD
BUTTON TOUCHPAD PELICAN
NS
SCREW RUBBER UPPER
RUBBER UP 14.1" BEZEL F3M
NS
SCREW RUBBER LOWER
RUBBER SCREW DOWN F3M
NS
NAME PLATE FOR BEZEL
MYLAR NAME PLATE PELICAN
No.
Partname
Description
