Acer 230 User Manual
Page 120
112
TravelMate 230/ 280
CN11
LCD Coaxial Cable Connector
SW1
SW1 Setting (Please see below)
CN12
Fan Connector
U18
CPU Socket
CN13
RTC Battery Connector
U34
Golden Finger (or Debug Board)
Keyboard Switch Settings
SW1-1
SW1-2
English OFF
OFF
Japanese
ON
OFF
Europe
ON
ON
Password Bypass Setting and BootBlock Setting
SW1-3
SW1-4
Check Password Enable
ON
OFF
BootBlock Enable
OFF
ON
