124 TravelMate 230/280
NS SCREW RUBBER UPPER RUBBER UP 14.1" BEZEL F3M
NS SCREW RUBBER LOWER RUBBER SCREW DOWN F3M
NS NAME PLATE FOR BEZEL MYLAR NAME PLATE PELICAN
NS LOGO LABEL FOR PANEL LABEL LOGO ON PANEL PELICAN
NS NAME PLATE FOR MIDDLE
COVER TM230 MYLAR PLATE NAME COVER
MIDDLE
NS LAUNCH KEY KEY LAUNCH PELICAN
Screws
NS SCREW SCR. HEX NUT W/WASHER&NYLOK
#4
NS SCREW SCREW M2L12 PH MSN+BZ
21 SCREW SCREW CPU MECH WAFER M2*L4
NI
23 SCREW SCREW M2.0*12 STEEL B
24 SCREW SCREW M2L4 BH MSN+BZ
25 SCREW SCREW M2L5 BH MSN+N
NS SCREW SCREW M2*3 NYLON 1JMCPC-
420325
26 SCREW SCREW
27 SCREW SCREW M2.5X6
NS SCREW SCREW M3x4(86.9A524.4R0)
NS SCREW SCREW WAFER NYLOK NI 2ML3
NS SCREW SCREW M2.5*4L NI
Picture No. Partname Description
