93
Merlin Protocol Analyzer User’s Manual CATC SW Version 2.0
Header Length Error
Indicates that a received Bluetooth data packet was terminated before all
bits of the packet header were received.
Payload Length Error
Indicates that the payload of a received Bluetooth data packet was either
longer than expected, or that a Bluetooth data packet terminated before the
expected end of the payload data.
Sync Loss
When set, indicates that a loss of piconet synchronization occurred during
the frequency slot prior to this slot.
External Input Signals
Clicking "External Input Signals" causes two check boxes to appear for
setting conditions based on breakout board input signals. The names of the
two check boxes are the same ones you will find on the break out board:
• Input 0 [TRIG IN 0]
• Input 1 [TRIG IN 1]
