Staub Electronics WPS-100-DVR-8CH WIREPATH - 8 CHANNEL DVR W_500GB HDD User Manual
Page 72
72
WPS-100-DVR-8CH Installation and Users Manual
• CAMERAS
Press the ENTER or +/- buttons on the front panel of the DVR or on the remote control to select
or deselect each of the cameras to be archived.
• END TIME
Press the +/- buttons on the front panel of the DVR or on the remote control to modify the Year, Month,
Date, Hour, and Minute for the recorded video and audio for the backup without playback of Search
by Time. The files will be backed-up from the start time to the end time when the user press the COPY
button to start copying.
Note : For each camera and each backup, a batch file will be generated as well as the backup .h264 files.
A directory titled “/SelfPlayer” will also be generated if it’s not already existing on the backup storage device.
The user can use the batch file to self-playback the corresponding backup files on a PC. If the PC has not been
installed with the required player components, those components will be installed by running the batch file (For
Windows Vista, please run /SelfPlayer/SelfPlayerInstall.exe manually to install the required player components).
To copy self-playback files, please copy the batch file and the backup files to the destination directory. Also
copy the entire “/SelfPlayer” directory to the root directory of the destination PC.
