Foredom Master Stone-Setting Kit User Manual
Page 8
cut height
cut
depth
cut height
incorrect,
off-center cut
Top view of ring setting showing center-cut prongs with evenly cut heights.
Close-up views of cut prongs
(Easy-Cut Prong Guide vs. freehand cutting)
The result—
a perfectly
set stone!
same distance from top of prong
Adjustment
for depth of
cut into prong
The Easy Cut Prong Guide produces consistent settings with perfectly even height and depth cuts.
Side view of ring setting showing center-cut prongs
with evenly cut heights.
correctly
centered cut
incorrect,
off-center cut
8
The Easy-Cut Prong Guide offers a wide range of adjustability.
Adjustment for smaller
settings/prongs
Adjustment for larger
settings/prongs
Rotational
force
Rotational
force
Rotational
force
Adjustment for
prong width
Adjustment for prong height
Allen bolt
adjustment
Allen bolt
adjustment
correctly
centered cut
