67
7. Speci
fi cations
IX-HNN70 (Arm Length 700, Ceiling-mount Specification)
Item Specifications
Type IX-HNN70-**L-T1
Degree of freedom Four degrees of freedom
Overall arm length 700
Arm 1 length 350
Arm 2 length
mm
350
Axis 1 (arm 1) AC servo motor + Speed reducer
Axis 2 (arm 2) AC servo motor + Speed reducer
Axis 3 (vertical axis) AC servo motor with brake + Belt + Ball-screw spline
Drive method
Axis 4 (rotational axis) AC servo motor with brake + Speed reducer + Belt + Spline
Axis 1 (arm 1) 750
Axis 2 (arm 2) 400
Axis 3 (vertical axis) 400
Motor capacity
Axis 4 (rotational axis)
W
200
Axis 1 (arm 1)  125
Axis 2 (arm 2)
degree
 145
Axis 3 (vertical axis) (*1) mm 200 (Optional: 400)
Movement range
Axis 4 (rotational axis) degree  360
Axis 1 + Axis 2 (maximum composite speed) 6597
Axis 3 (vertical axis)
mm/sec
1583
Maximum
operating speed
(*2)
Axis 4 (rotational axis) degree/sec 1200
Axis 1 + Axis 2  0.015
Axis 3 (vertical axis)
mm
 0.010
Positioning
repeatability (*3)
Axis 4 (rotational axis) degree  0.005
Cycle time (*4)
0.50
Rated 5
Load capacity
Maximum
kg
20
Dynamic (*8) 265 (27.0)
Push-in thrust of
axis 3 (vertical axis)
Static (*9)
N (kgf)
188 (19.1)
Permissible moment of inertia (*5) kgm 2 0.1
Permissible load
on axis 4
Permissible torque Nm (kgfcm) 6.7 (68.3)
Permissible tool diameter (*6) mm  100
Origin detection Absolute
User wiring D-sub 25-pin connector with 25-core AWG26 shielded cable (socket)
Alarm indicator (*7) One small, red LED indicator (rated voltage: 24 V)
User piping
Two air tubes (outer diameter: 6, inner diameter: 4) (normal service pressure: 0.8 MPa)
Two air tubes (outer diameter: 4, inner diameter: 2.5) (normal service pressure: 0.8 MPa)
