10. Explanation on Each Function Screen
(Super SEL Type)
F1 F2 F3 F4
Test 0123456789 (Flg)
600 __ > 1100000000 < __ 609
610 __ > 0000000000 < __ 619
Inc Dec Clr Wrt Test
Flag
In
Out
Ver
Inc
Dec
Clr
0/1
Test
Flag
In
Out
Ver
Inc
Dec
Clr
0/1
(DS Type)
Flag forced ON/OFF is possible with this
screen. However, it does not monitor flag
changes in realtime.
Test Input Port Display
(Super SEL type)
Test
Flag
In
Out
Ver
Inc
Dec
Test
Flag
In
Out
Ver
Inc
Dec
(DS Type)
You may display input port changes, and input the input port.
As for the input port, you can execute the realtime • monitor,
and turn it ON/OFF using a peripheral device. The standard for a
Super SEL type is up to 023 while it is up to 015 for the DS type.
F1 Key (Inc): +10 to Flag.
F2 Key (Dec): -10 to Flag.
F3 Key (cir): Turns all displayed port to 0.
F4 Key (0/1): Changes
→
0
➯ 1, 1
➯ 0
Moves .(decimal point) , Return Key
→
Cursor location to the right.
Moves -(minus) Key
→
Cursor location to the left.
F1 F2 F3 F4
Test 0123456789 (In)
000 __ > 0010000000 < __ 009
010 __ > 0000000000 < __ 019
Inc Dec __
F1 Key (Inc): +10 to Display Port.
F2 Key (Dec): - 10 to Display Port.
Test Flag Display
