8. Examples of Simple Operation Procedure
F1 F2 F3 F4
Edit 1- 2 [ 1]
VEL 100
F1 F2 F3 F4
Edit 1- 2 [ 1]
VEL 100
F1 F2 F3 F4
Edit 1- 3 [ 2]
_
TIMW VEL WTOF WTON
And Or Clr Not
F1 F2 F3 F4
F1 F2 F3 F4
Edit 1 - 3 [ 2]
MOVL
MOD MOVL MOVP MULT
MOD MOVL MOVP MULT
Edit 1 - 3 [ 2]
_
Clr Not
Press the Return Key.
Press the F4 Key, and advance to Step No.3.
Continuously press the DEC / - Key until MOVL is
displayed.
In this example, select the F2 Key (MOVL).
[Note: In some cases, the displayed function key location
(F1~F4) of MOVL may differ.]
Press the Return Key. Then, input 1 for Position No. into
operand 1.
?
The difference between MOVL and MOVP:
MOVP moves the actuator to the designated position number from point to point without interpolation.
MOVL moves the actuator to the designated point while using interpolation (not point to point).
