F1 F2 F3 F4
F1 F2 F3 F4
③ Data input for point 3
Input 100 into the position data for axis 1, then press
the Return Key.
Using the F1 Key (Wrt) to establish, then, advance the
Position No. to 3.
F1 F2 F3 F4
Mdi - 3 No 2 [2] - 2
XXXXX.XXX XXXXX.XXX
Wrt Can Clr Etc
Input 50 into position data for axis 2, then press the
Return Key.
Mdi - 2 No 2 [2] - 2
50.000 XXXXX.XXX
Wrt Can Clr Etc
Since the cursor position moves to the position
data for the axis 2, input 100 and press the Return Key.
Mdi - 2 No 1 [1] - 2
50.000 100. 000
Wrt Can Clr Etc
8. Examples of Simple Operation Procedure
F1 F2 F3 F4
Mdi - 3 No 1 [1] - 2
100.000 XXXXX.XXX
Wrt Can Clr Etc
F1 F2 F3 F4
Mdi - 3 No 1 [1] - 2
100.000 50.000
Wrt Can Clr Etc
Press the F1 Key (Wrt), then, advance Position No.
to 4.
