Securitron ZA-82 User Manual
Page 3
PN#
500-10750
Page 3
Rev. E, 03/11
(RECOMMENDED)
3/4" [19.1MM]
DOOR HEADER
LOCK
STRIKE
ZA BRACKET
(TEETH)
DOOR STOP
SEX BOLT
2X
5/16" BOLTS
DOOR
[112MM]
4.4
2-1/4" TO 3-1/2" [57MM TO 89MM]
ADJUSTABLE
Figure 1
SEX BOLT
PLASTIC STRIKE
BUSHING
UPPER BRACKET - STRIKE MOUNTING:
A) FOR T-NUT:
DRILL THRU
3/8" [9.5MM]
B) FOR ROLL PIN(S):
DRILL THRU:
3/8" [9.5MM]
(IF PLASTIC BUSHING IS NOT USED)
- DRILL
1/2" [12.7MM] FOR BUSHING
LOWER
BRACKET
5/16-18 X 1-1/2"
SHCS
2X
#14 X 1-1/4"
2X
5/16-18 FLANGED
LOCKNUT
STRIKE
2X - 4X
RUBBER SPACER
WASHERS
2X
PLASTIC ROLL PIN
BUSHINGS (CUT SHORT)
(OPTIONAL)
T-NUT
2X
5/16-18 X 1" HEX
FLANGED SCREW
MAGNALOCK (M62F SHOWN)
MOUNTED TO DOOR HEADER
USING HARDWARE PROVIDED
WITH LOCK
COVER
*5/16-18 FHS
*USE SHORT (1" LONG) 5/16-18 FHS
PROVIDED WITH ZA BRACKET
DOOR PREPARATION FOR LOWER BRACKET:
A) FOR SEX BOLT:
DRILL
3/8" [9.5MM] THRU DOOR - THEN
DRILL
1/2" [12.7MM] X 1.5" [38.1MM] DEEP
FROM THE SEX BOLT SIDE OF THE DOOR
B) FOR #14 SCREWS:
DRILL
3/16" [4.8MM] X 1" [25.4MM] DEEP
Figure 2
