GENERAL SPECIFICATIONS
Distance between
transmitter and receiver
Transmission frequency 910MHz (CMR35) or 912.4MHz (CMR35A)
Sampling rate Three times/second with no transmission;
once/sec with transmission
Number of data logs Unlimited
storable
Operating temperature/ 14° to 122°F (-10° to 50°C) at less than 80% relative
humidity humidity (noncondensing)
Storage temperature/ -4° to 140°F (-20º to 60°C) at less than 70% R.H.
humidity (noncondensing)
Power supply Two “AA” Alkaline batteries each for transmitter and
receiver. Alternatively (receiver only), via 3-V AC/DC supply
at 10 mA through 3.5mm stereo mini-plug
Transmitter Receiver
Battery life
Without transmission:
300 hours
With transmission With transmission span
span of 2 seconds: of 2 seconds:
~100 hours ~100 hours
LCD size 2.05(H) x 1.14(W) in. 1.77(W) x 1.04(H) in.
(52 x 29mm) (45 x 26.5mm)
Dimensions 8.66(L) x 2.52(W) 7.05(L) x 2.83(W)
x 1.38(H) in. x 1.26(H) in.
(220 x 64 x 35mm) (179 x72 x32mm)
Maximum clamp opening 0.39 x 1.38 in.
(10 x 35mm)
—
Weight 8.85 oz. (251g), 6.24 oz. (177g),
excluding batteries excluding batteries
32
333 ft. (100m) maximum; less with obstacles in path and
when either unit is inside metallic structure
