Section 3: Highway System Mode of Operation
7/08 23 51188 Rev. 1
3.4.2. Specialized Keys, Continued
On-Screen
Keyboard External
Keyboard Description
- - - -
• F3 displays the list of Inbound Records during the Outbound entry of
the Truck/Loop ID while in HW System Operation.
• Selects GTN Format while in Ticket Formatting Operation .
- - - - • F4 activates the Void Ticket function while in HW System Operation.
- - - -
• F5 opens the Format Ticket menu while in Ticket Formatting
Operation
- - - -
•
F6 activates the Delete Ticket function while in Ticket Formatting
Operation
- - - -
• F7 o pens the View Printers window while in Ticket Formatting
Operation
- - - -
•
F8 opens the Add Printer function while in Ticket Formatting
Operation
- - - -
• Esc button Cancels/aborts the function.
• Reverts to previous window.
- - - -
If entering weighment data, pressing this displays the Print, Edit , and
Cancel buttons regardless of which data item is being entered.
Print
Prints a ticket, but only when the Print button displays.
- - - -
• Enters weighment data, and the last data item processed.
• Displays the Print, Edit , and Cancel buttons.
Toggles the Traffic Light if set for Manual control.
Toggles the Traffic Light during the Axle Selection Process.
Toggles the displayed Video Image , if so configured.
Mimics the Exit Application button.
NOTE: Function Keys ( F-Keys ) 9 thru 12 are not used.
+
+
+
+
