Menu navigation, Main weighment screen, Specialized keys – Fairbanks FB3000 Highway System Application User Manual
Page 22
Section 3: Highway System Mode of Operation
7/08
22
51188 Rev. 1
3.4. MENU NAVIGATION
3.4.1. Main Weighment Screen
3.4.2. Specialized Keys
On-Screen
Keyboard
External
Keyboard
Description
This key
Zeros the Scale,
once the truck is scale-borne.
Toggles the
Weight Units
.
Arrows
Arrows
• Navigates through the display.
• Used also for scrolling.
•
F1
turns the camera
on
, if available, while in HW System Operation.
• Selects
Inbound Format
while in
Ticket Formatting Operation.
•
F2
turns the camera
off
, if available, while in HW System Operation.
─
Screen displays black when idle, then red when a truck drives on it.
• Selects
Outbound Format
while in
Ticket Formatting Operation.
Displayed above is the
Highway Program
default
screen with the video camera option.
