The LPF-1 is a low-pass filter designed to remove the high frequency spikes on the LASAR Ignition RPM
output. Without this filter the RPM readings on the CGR unit may display jumpy readings at various engine
RPMs. The LPF-1 should be installed between the LASAR RPM output and the EDC RPM input.
Rev: New 5/2/07
LPF-1 Used with the CGR System: LPF-1 Used with the CGR System: LPF-1 Used with the CGR System: LPF-1 Used with the CGR System: LPF-1 Used with the CGR System:
Brn/Wht Wire
to EDC Pin 26
LPF-1 LPF-1 LPF-1 LPF-1 LPF-1
Blk Wire to
EDC Pin 8 (Gnd)
EDC EDC EDC EDC EDC
Bottom Connector
LASAR RPM
output signal LASAR LASAR LASAR LASAR LASAR
I n g i t i o n I n g i t i o n I n g i t i o n I n g i t i o n I n g i t i o n
System System System System System
White Wire
A1.0 Appendix
LASAR Ignition RPM Filter
A1.0
C G R C G R C G R C G R C G R
