Specifications, Functions and Features
0226131
Rev. New
Models: CGR-30P and EDC-33x
CGR-30P
Weight: 1.9 Lbs.
Environmental: Designed and Tested to TSO (DO-160G, See Enviornmental Qualification Form)
Software: Designed and Documented to TSO (DO-178B, Level C)
Minimum Performance Standards: TSO-C43c, TSO-C44c, TSO-C45b, TSO-C47a, TSO-C48,
TSO-49b and TSO-C55a.
Power Requirements: 7.5 to 30 Volts, 0.26 amps @ 24V (Typ), 0.36 amps @ 12 Volts (Typ).
USB Port: For USB Memory Stick use only.
Display: Active Matrix TFT, 262,144 colors, Sunlight readable
Backlight: External control line, Programmable Levels
EDC-33x
Weight: 1.0 Lb
Environmental: Designed and Tested to TSO (DO-160E, See Enviornmental Qualification Form)
Software: Designed and Documented to TSO (DO-178B, Level C)
Power Requirements: 7.5 to 30 Volts, 0.1 amps (Typ).
Accuracy all Functions: < 1% (Unless otherwise noted)
Input Configuration: EDC-33P; 1-Volt Channel, 1-Amp Channel, 1-Fuel Flow Channel,
6-Pressure Channels, 17-Temp Channels, 4-Resistive Fuel Level
Channels, 4-Capacitive Fuel Level Channels and 2-RPM Channels.
Note: Temp and Fuel Level channels can be used to monitor other functions or
annunciators.
