Paramagnetic O2 Purity Analyzer

Appendix

Teledyne Analytical Instruments

81

Appendix

A-1 Model 3010MA Specifications

Sensor:

Paramagnetic

Range: 3 ranges, user selectable from 95-100% O

2

Alarms: One system-failure alarm contact to detect

power failure

Two

adjustable

concentration

threshold

alarms with fully programmable setpoints.

Displays: 2 line by 20 character, alphanumeric, VFD

screen
One 5 digit LED display

Digital Interface: Full duplex RS-232 communications port.

Power: 100-130, or 200-240 VAC, at 47/63 Hz.

(User selected on rear of control unit)

Operating Temperature: 20-30

°C

Accuracy: ±0.045%

O

2

absolute at constant

temperature (once thermal equilibrium has
been achieved)
±0.05% O

2

over operating temperature range

20-30

°

C (once thermal equilibrium has been

achieved)

Response

Time: 10%

-

90%

in

14

sec

@

600

SCCM

Analog outputs: 0-1 V dc percent-of-range (Standard)

0-1 V dc range ID (Standard)
4-20 mA dc—isolated— percent-of-range
4-20 mA dc—isolated— range ID (Special
option)

Dimensions: 17.7 cm high

×

24.9 cm wide

×

30.5 cm

deep (6.96

Ч

8.7

Ч

12.2

).

Weight: Analysis:

(7.8Kg)

17.2Lbs

Control unit: (8.2 Kg) 18Lbs
