Part 1 Control Unit
Model 3010MA
Teledyne Analytical Instruments
36
12 (-)
Remote
Span
37 System
Alarm,
NO
Contact
13
38 Range
1
ID
Contact
14
39 Range
2
ID
Contact
15
Remote ZERO valve (return)
40
Cal Contact
16
Remote SPAN valve (return)
41
Cal Contact
17
Remote SPAN valve (hot)
42
18 Range
3
ID
Contact
43
19 Range
3
ID
Contact
44
20
System Alarm Moving Contact
45
21 Range
1
ID
Contact
46
22 Range
2
ID
Contact
47
23
(-) Range ID, 0-1 V dc neg gnd
48
Remote EXHAUST valve (return)
24
(+) % Range, 0-1 V dc
49
Remote ZERO valve (hot)
25
50 Remote
SAMPLE
valve
(return)
* Available by special option only.
3.3.2.4 RS-232 P
ORT
The digital signal output is a standard RS-232 serial communications
port used to connect the analyzer to a computer, terminal, or other digital
device. It requires a standard 9-pin D connector.
The data is status information, in digital form, updated every two
seconds. Status is reported in the following order:
•
The concentration in percent
•
The range in use (HI, MED, LO)
•
The span of the range (95-100%, etc)
•
Which alarms—if any—are disabled (AL–x DISABLED)
•
Which alarms—if any—are tripped (AL–x ON).
Each status output is followed by a carriage return and line feed.
Four input functions using RS-232 have been implemented to date.
They are described in Table 3-1.
