Part 1 Control Unit

Model 3010MA

Teledyne Analytical Instruments

x

Preface

Overview

The Teledyne Analytical Instruments Model 3010MA Paramagnetic

Oxygen Purity Analyzer is a versatile microprocessor-based instrument for
analyzing the purity of an oxygen bearing gas stream. It is a “split
architecture” instrument designed for indoor use in non-hazardous areas.
The Control Unit contains the operator interface, electronics and display.
The Analysis Unit is a separate insulated and temperature controlled
enclosure which contains the oven, sensor, sample system and flowmeter.

Part I of this manual covers the Model 3010MA flush-panel and/or

rack-mount Control Unit. The Analysis Unit is covered in Part II of this
manual.

Typical Applications

A few typical applications of the Model 3010MA are:

• Monitoring

inert

gas

blanketing

• Air

separation

and

liquefaction

• Chemical reaction monitoring

• Semiconductor

manufacturing

• Petrochemical

process

control

• Quality

assurance

Gas analysis certification.

Main Features of the Analyzer

The Model 3010MA series Paramagnetic Oxygen Analyzers are

sophisticated yet simple to use. The main features of these analyzers
include:

• A 2-line alphanumeric display screen, driven by microprocessor

electronics, that continuously prompts and informs the operator.
