Paramagnetic O2 Purity Analyzer

Introduction

Teledyne Analytical Instruments

15

Introduction

1.1 Overview

The Teledyne Analytical Instruments Model 3010MA Paramagnetic

Oxygen Purity Analyzer is a versatile microprocessor-based instrument
for detecting the percentage of oxygen in a gas stream. This part of the
manual covers the Model 3010MA flush-panel and/or rack-mount Control
Unit. These units are for indoor use in a nonhazardous environment.

In addition to supplying the interface for operating and controlling

the analyzer, the Control Unit also houses:

Main circuit board

PID temperature controller

Pressure compensation circuitry

24 VDC power supply for driving the Analysis Unit

Digital meter readout and display circuit board

Interface screen and circuit board

1.2 Front Panel (Operator Interface)

The standard 3010MA is housed in a rugged metal case with all

controls and displays accessible from the front panel. See Figure 1 -1. The
front panel has thirteen buttons for operating the analyzer, a digital meter,
and an alphanumeric display.

Function Keys:

Six touch-sensitive membrane switches are used to change the

specific function performed by the analyzer:

Analyze—Perform analysis for oxygen content of a sample gas.

System—Perform system-related tasks (described in detail in
chapter 4, Operation.).

Span—Span calibrate the analyzer.

Zero—Zero calibrate the analyzer.
