Trace Nitrogen in Argon Analyzer Installation
Teledyne Analytical Instruments 17
Installation
Installation of the Model 2120XL Trace Nitrogen in Argon
Analyzer can involve potentially hazardous procedures.
CAUTION: INSTALLATION SHOULD BE PERFORMED ONLY BY
TRAINED AND QUALIFIED PERSONNEL WHO HAVE
READ AND UNDERSTOOD THE INSTRUCTIONS IN
THIS MANUAL.
Installation of the Model 2120XL Trace Nitrogen in Argon
Analyzer includes:
 Unpacking
 Choosing an Appropriate Location
 Mounting
 Electrical connections
 Gas connections
 Purging
 Calibration
3.1 Unpacking the Instrument
The analyzer is shipped with all the materials you need to install
and prepare the system for operation. Carefully remove the analyzer from
the shipping container and visually inspect it for damage. Maintain it in an
upright position and avoid jarring. Ensure the power cord and calibration
data sheets are included and that all components ordered have been
supplied. Remove any plugs that may be installed on the gas tube fittings
on the rear panel.
If any items are missing or the analyzer appears damaged,
immediately report any damage to the shipping agent and notify
Teledyne. Remove and discard caps from fittings; inspect the analyzer
for loose fittings or connections.
