PINKERTON Installer Manual
PINKERTON
T
ERMINAL
C
ONNECTIONS
AC
16VAC supply from plug pack.
AC
16VAC supply from plug pack.
KP
Remote keypad/s blue wire.
D-
Common for Zones
Z1
Zone 1 input. 4.7K end of line resistor.
Z2
Zone 2 input. 4.7K end of line resistor.
Z3
Zone 3 input. 4.7K end of line resistor.
Z4
Zone 4 input. 4.7K end of line resistor.
D-
Common for Zones
Z5
Zone 5 input. 4.7K end of line resistor.
Z6
Zone 6 input. 4.7K end of line resistor.
Z7
Zone 7 input. 4.7K end of line resistor.
Z8
Zone 8 input. 4.7K end of line resistor.
KY
Keyswitch input. Apply momentary negative voltage to arm or disarm the panel. Also used to
restore the Installer code to factory default setting.
Hold a negative voltage on KY while applying power to board.
AX
Remote keypad/s white wire.
D+
12VDC positive supply for detectors. Also remote keypad/s red wire.
D+
12VDC positive for supply to detectors.
D-
12VDC negative supply for detectors. Also remote keypad/s black wire.
D-
12VDC negative supply for detectors. Also common for siren and strobe.
SI
Siren output. 12VDC positive when in alarm.
ST
Strobe output. 12VDC positive when in alarm.
D-
Common for External Input Zones
DU
Duress input. 4.7K end of line resistor.
PA
Panic input. 4.7K end of line resistor.
TE
Test input. 4.7K end of line resistor.
LINE
Incoming
Telephone
Line.
PHONE
To First Telephone point.
