10 PINKERTON Installer Manual
PINKERTON K EYPAD
K EYPAD INDICATOR LIGHTS
Listed below are the use of the indicator lights when in normal operation.
Keypad
Light Light ON Light OFF Light Flashing
On-Line Dialler on line Dialler not on line Dialler had problems
Low Batt Battery Charge Voltage
Low Battery OK Had Low Batt alarm
AC Fail Power not connected Power OK Had AC fail alarm
On SYSTEM is on (Away
mode) SYSTEM is off SYSTEM is on (Home
mode)
Chime Chime Mode is ON Chime Mode is
OFF
Zone 1 - 8 Unsealed, Manual or Auto
isolated Zone is sealed Had alarm
Note that the status of the Zones will always be displayed unless disabled by the installer. The
Low Batt and AC Fail lights will show the current state of these inputs, however the alarm (or
restore) condition may have to be present for a period before a report is initiated.
If the dialler fails to communicate, the On-Line light will remain flashing until the next time the
system is turned off.
All Zone lights on plus a continuous beeper
Means the keypad is locked out for 60 seconds caused by 4 consecutive incorrect code entries.
All Zone lights flashing
Indicates a legal code has been entered (or the key) and the SYSTEM expects another key to
be pressed to select the desired function within 10 seconds.
To cancel simply wait 10 seconds or press the key.
K EYPAD B EEPER O PERATION
The keypad beeper will sound under the following circumstances:
Any key press short beep
Turn SYSTEM OFF short beep
Turn SYSTEM ON (only heard if exit beep is disabled) 3 short beeps
Display of new data in programming mode 2 short beeps
Wrong key or illegal action Long beep
Press key
Long beep
In Home Mode when a Home Beep Zone is triggered Short beep
Keypad lockout due to too many code entry attempts Continuous beep
During exit delay if Exit Beep is enabled Continuous beep
At end of exit delay if Exit Beep is disabled 3 short beeps
During entry delay if Entry Beep is enabled Continuous beep
